EATON FHF AX03 Sounder 115/230V AC IP66

The EATON (FHF) AX03 sounder, part of the Crouse-Hinds series, is a compact, high-volume signalling device with good directivity, suitable for both indoor and outdoor use thanks to its IP66 ingress protection rating. It offers 32 different signal tones and is designed for two-stage alarm operation, making it suitable for a wide range of industrial signalling and alarm applications.

Technical Specifications:

• Product code (Art. No.): FHF 215 310 07
• Type: AX03 Sounder
• Nominal voltage: 115/230V AC
• Operating voltage: 115/230V
• Sound level: 100-111 dB(A)
• Weight: 0.4 kg
• Housing material: ABS
• Colour: Red
• Tones: 32 different signal tones, 2 more may be added externally
• Ingress protection: IP66 per IEC 60529
• Operating temperature: -25°C to +70°C
• Connection terminals: 2.5mm² (single-wire) / 1.5mm² (fine-wire)
• Use: Indoor & outdoor, continuous operation
• Manufacturer: EATON (FHF) – Crouse-Hinds Series

Ideal for industrial installations, marine applications, and alarm systems requiring reliable high-level audible signalling.
